Frame Mounted Hydraulic Cooler
The THERMAFLOW SS600 hydraulic cooler is the original SS934. The SS600 and the SS934 have almost identical capabilities but the SS600 is a wider unit. It is a hydraulic cooler designed to be conveniently mounted on the frame rail just like the SS934. User preference is the only real difference between these two siblings. The SS600 hydraulic cooler will drive most 3″& 4″ product pumps and compressors, with options for multi-pump applications, it is able to support applications such as, chemicals, compressed gasses, food grade, crude oil, vacuum pumps and combo drives..
Stainless steel construction ensures long life and good looks. Heavy duty shock mounts are supplied standard, to isolate road vibration.
Entire front panel quickly removes to allow easy access to all parts.
No-Mess Oil Filter Replacement:
Unique filter design allows replacement from top of unit, rather than the bottom, preventing oil spillage and unneccesary mess.
Flow Rate: 30 gpm
Max Pressure: 5000 psi
Reservoir: 3.5 gallons
Warranty: 2 years
Dimensions: 15″ x 17.5″ x 20″
Suction port size: 1 1/2″ NPT (Male)
Pressure port size: #12 JIC (Male)
Return port size: #12 JIC (Male)
The standard relief valve offers pressure protection.
Directional Control (V):
A directional control valve allows for easy rotation changes or drive selection.
The Electric fan motor option has a 12VDC cooling fan which is operated with a temperature control switch. This switch gets wired into keyed power. When the key is turned on, the switch will be ready to activate the fan when the oil temperature gets to 110°F. When the oil temperature falls to 105°F the fan will turn off.
The Hydraulic fan motor option has a fixed pressure compensated flow control that automatically cycles the fan “ON” when the hydraulic system is running and “OFF” when not running. This option comes plumbed from the factory.
